Technical specification of Bus Duct
| Specification | Customization Available |
|---|---|
| Voltage Rating | Customizable for voltage ratings up to 1100V, suitable for medium to low voltage applications. |
| Current Rating | Available in current ratings from 100A to 6300A to support a wide range of electrical loads. |
| Busbar Type | Options for aluminum or copper busbars, based on load requirements and efficiency needs. |
| Insulation Type | Can be customized with thermosetting or thermoplastic insulation for improved electrical safety. |
| Enclosure Material | Available in sheet metal & stainless steel enclosures for protection against environmental factors. |
| Length and Dimensions | Custom lengths and dimensions to fit installation space and provide optimal power distribution. |
| IP Protection Rating | Customizable IP ratings from IP2x to IP6x for protection against dust, moisture, and outdoor conditions. |
| Cooling Mechanism | Options for natural ventilation or forced air cooling, depending on power load and ambient conditions. |
| Mounting Configuration | Available in structural mounted and ceiling suspended configurations for flexibility in installation. |
| Busbar Configuration | Available in both single-phase, three-phase, or multi-phase configurations to suit project requirements. |
| Current Limiting | Custom current-limiting fuses or breakers can be incorporated for overload protection and safety. |
| Short-Circuit Withstanding | Options for panels designed to withstand high short-circuit currents as per specific system standards. |
| Metering | Integration of digital or analog meters to monitor voltage, current, power, and energy consumption. |
| Communication Interface | Custom integration with SCADA or PLC systems for remote monitoring, fault detection, and control. |
| Busbar Covering | Available with insulated or non-insulated busbar covers for additional safety in high-voltage environments. |
Features
- The Bus Duct is engineered for efficient power transmission with minimal energy dissipation.
- Its modular design allows flexible installation in complex electrical networks.
- High-grade insulation ensures safety and protection against short circuits.
- Customization options support diverse voltage and current requirements.
- Durable construction enhances lifespan and reduces maintenance efforts.
